operation directly with buttons or using communication objects for confirmation to show current status.
4.2.2.1.1# Parameters#
Parameter
Setting
Description
Command on Press
On / Off / Toggle / No command
Selects button function when button pressed.
Command on Release
On / Off / Toggle / No command
Selects button function when button released.
Function of LED
LED permanently Off
LED always Off
LED permanently On
LED always On
Status Indication
Last transmitted command “on” -> LED on
Last transmitted command “off” -> LED off
If “Separate Comm Object” enabled, status
LEDs will wait for confirmation before
changing status.
Inverted Status Indication
Last transmitted command “on” -> LED off
Last transmitted command “off” -> LED on
If “Separate Comm Object” enabled, status
LEDs will wait for confirmation before
changing status.
Operation Indication
Status LED of the pressed push button will be
on for the time period selected at “Light
Duration of LED” parameter at “General” tab.
Last transmitted command value has no effect
to the status led operation.
Separate Comm Object
Enable/Disable
Only visible when “Function of LED” selected
as “Status Indication” or “Inverted Status
Indication”. This communication objects is the
input of confirmation for status LEDs. If
selected “Enable” respective communication
object should be linked to an appropriate
group address.
Table 16
4.2.2.1.2# Communication#Objects#
No
Object Name
Function
Data Type
Flags
1
PushButton1
switch
1 bit
DPT 1.001
CWT
On/Off telegrams will be send to group address that is linked to this communication object.
3
PushButton1
Status Comm.Obj.
1 bit
DPT 1.002
CWT
Confirmation for On/Off switch telegrams will be received from this communication object. If these
communications object visible, it must link to an appropriate group address. Otherwise status LEDs will not
function correctly. If status confirmation not to be used the communication object should be disabled by
“Separate Comm Object” parameter.
Table 17
