Eagle Access Control Systems Eagle-2000 series - Secondary Entrapment and Motor Reset; Mounting The Secondary Entrapment; Resetting The Motor

Mounting The Secondary Entrapment
Note: Eagle Access Control Systems, Inc.
recommends the installation of Edge Sensors
on all sliding gate operator systems.
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series
____________________
Distributed by AFW Access Systems • www.AnchorMiami.com/afwas
(20)
Resetting The Motor
On all Eagle Access motors, a red reset button is available for resetting the motor.
If operator ceases to function:
then simply locate the reset button, press, and then turn the power back on.
____________________
EMERSO
MOTOR
LEESON
MOTOR
Edge Sensors should be
appropriately installed at
recommended locations to
ensure proper entrapment
protection against injury.
All Edge Sensors are shown
at recommended locations.
*
All Contact Sensors
Are Connected To
Edge Sensor Inputs
Eagle Operator
EDGE SENSORS
WALL WALL
GATE OPENING
*
*
*
*
**
(TOP VIEW)
TURN THE POWER TO THE OPERATOR OFF
AND ALLOW FOR THE MOTOR TO COOL DOWN...
