- 10 -
2.2 Transportation
You must have at least 4ft fork tubes or tube extensions fully inserted into the machine and a forklift
rated for 3,000lbs to transport the machine safely. Do not raise the load more than 6” off of the
ground. (See Fig. 2-2)
ALWAYS USE OSHA HANDLING PROCEDURES FOR HANDLING THE
STRETCH WRAPPER AND REMEMBER TO NEVER PUSH, DRAG, OR
SLIDE THE MACHINE!
Do not transport machine from turntable when mast is
lowered!
When transporting the machine in this configuration;
1. Inspection cover must be removed before raising or
lowering the mast.
2. Carriage must be raised 8 inches
Carriage must be raised 6~8 inches before attempting
to lift machine from this end.
It is acceptable to transport machine by turntable when
mast has been raised.
Fig. 2-2
