- 31 -
5.2 Carriage Load Safety Switch
USE EXTREME CAUTION WHEN ADJUSTING
CARRIAGE SWITCH AS IT CAN BE DAMAGED
BY OVER ADJUSTMENT
Step 1 - Open Carriage Door
Step 2 - Unload any and all stretch film from machine
Step 3 - Loosen jam nut
Step 4 - Loosen bolt in small increments to avoid damage to switch
Step 5 - Close carriage door gently (Do not install stretch film)
Step 6 - If the machine is able to reset, then the carriage door switch
is adjusted correctly. If the machine does not reset, then
repeat steps 4 & 5
Step 7 - Open carriage door and tighten jam nut
Step 8 - Reinstall stretch film
