- 36 -

6.1 Illustration

Base (continued)

Name Part Numbe

1 Turntable FG-01A-19 1

2 Idler Gear FG-01A-18 2

3 Block Limit Switch FG-12A-16 1

4 Ramp Bolt 1

5 Idler Wheel FG-01A-20 24

6 Turntable Gear FG-01A-13 1

7 Limit Switch N1CA2 1

8 Chain 12A 1

9 Base Frame n/a 1

10 Tension Screw 91292A217 1

11 Motor Gear FG-01A-31 1

12 Motor Mount Plate FG-01A-28 1

13 Main Motor CV750-30S 1

14 Cover FG-01A-27 1

15 Motor Fan Cover 1

16 Fan Motor Cover 1

17 Mast Pin 1
