Eagle 2000 BWS - Page 41

- 41 -
6.4 Illustration
Carriage – Continued from previous page.
Name Part Numbe
r
Qt
y
1 Motor Cover FG-08T-20 1
2 Gear Box NMRV40-10-YS6344 1
3 Carriage Top Plate FG-08T-02 1
4 Film Lifter FG-08T-00 1
5 Roll Holder FG-03A-18 1
6 Core Holder Shaft FG-03A-16 1
7 Core Holder Washer FG-03A-21 1
8 Core Holder FG-03A-19 1
9 Protection Plate/ Bottom Plate FG-08T-16 1
10 Micro Switch 7779K22 2
11 Roller Bearing 5972K168 1
12 Large Carriage Gear FG-03-14 1
13 Carriage Prestretch Chain 06B 1
14 Small Carriage Gear FG-03-12 1
15 Film Roller Assembly FG-08-07 1
16 Roller Door FG-08-14 1
17 Extended Roller Assembly FG-08-08 1
18 Right Connection Block FG-08-20 1
19 Left Connection Block FG-08-20 1
20 Film Tension Switch FG-03-11 1
21 Main Roller FG-03-02 1
22 Pin Release Bar Assembly FG-08-17 1
23 Film Roller FG-03-03 1
24 Carriage Door Bracket FG-08-04 1
25 Photo Eye Switch A3R-2MX 1
26 Photo Eye Bracket FG-08-21 1
27 Spring Bolt FG-08-18 2
28 Spring FG-08-17 2
29 Shrink Ring FG-03A-20 1
30 Rivet Bolt M10 1
