- 6 -
1.2 Specifications - Eagle 2000BE
Power Supply 110VAC, 60Hz
Turntable Speed
(Standard 0-12 rpm) (Optional 0-20rpm)
1
Turntable Motor 1 HP 750W 1420 RPM 220V 1:30 Gearbox
Turntable Diameter 59”
Turntable Diagonal 80”
Turntable Height 3.4”
Turntable Gear 1:5
Turntable Chain 12A-1 ISO
Carriage Up/Down 1/3 HP 1390 RPM 220V 1:60 Gearbox
Carriage Up/Down Chain 08B-1 ISO
Pre-Stretch Motor 1/3 HP 1390 RPM 220V 1:20 Gearbox
Pre-Stretch Gear Ratio 1:12
Pre-Stretch Chain 06B-1 ISO
Film Stretch 250% pre-stretch with adjustable load force
Film Lift
Photo-eye controlled to match pkg height
2
Film Width 20” (standard) or 30” (option)
Adjustable Internal Limit Switches 8” Top & Bottom Rails
Max Film Height 120”
Mast Height 126.5”
Max Turntable Weight Capacity 5,000lbs
Max Package Height (2” Overlap) 118”
Machine Dimensions 96.5” X 59” X 130”
Shipping Weight 2,060lbs
Attachment
Ramp or Custom Heavy Duty
3
Noise ≤75 DB
Environment Humidity ≤98% Temperature 32-104°F
1
Note: Black product requires custom photo-eye installation.
2
Factory ramp is for use with hand pallet jacks only. Maximum combined weight of jack and product must not
exceed 1,300lbs. Custom heavy-duty ramps are available for use with loads exceeding 1,300lbs. (See page 5
for details)
3
Turntable maximum RPM can be increased to 20 RPM upon request.
