8
For all standard model UPS, it is advised to charge the batteries over 8 hours
before using. Once the AC mains power energizes the UPS, it will automatically
charge the batteries. Without prior charging, UPS output remains as usual but with
shorter back-up time than normal.
When connected to motor, display equipment, laser printer etc, UPS power
selection should be based on the startup power of the load which is usually twice
as rated power.
Wiring by a qualified electrician is required. Ensure input cables and output cables
are connected correctly and firmly.
If install a leakage current protective switch, please install it on output cable.
For 1-3K series long backup model units, you may need to prepare wires for
terminals based on the following table.
Model
Wiring spec (AWG)
Input Output Battery
Non-isolated
Ground
1kVAS_DC24V 1mm² 1mm² 6mm² 1mm² 1mm²
1kVAS_DC36V 1mm² 1mm² 4mm² 1mm² 1mm²
1kVAH_DC36V 1mm² 1mm² 4mm² 1mm² 1mm²
2kVAS_DC48V 1.5mm² 1.5mm² 6mm² 1.5mm² 1.5mm²
2kVAS_DC72V 1.5mm² 1.5mm² 4mm² 1.5mm² 1.5mm²
2kVAH_DC72V 1.5mm² 1.5mm² 4mm² 1.5mm² 1.5mm²
3kVAS_DC72V 2.5mm² 2.5mm² 6mm² 2.5mm² 1.5mm²
3kVAS_DC96V 2.5mm² 2.5mm² 4mm² 2.5mm² 1.5mm²
3kVAH_DC96V 2.5mm² 2.5mm² 4mm² 2.5mm² 1.5mm²
3.3 Installation and output connection
Normally, output connection of 1~3kVA series is configured with power outlets or
terminal blocks, users can plug the load cable into the UPS power outlets to energize
the load. Make sure the mains cable and breakers in the building are enough for the
rated capacity of UPS to avoid the hazards of electric shock or fire.
3.4 External batteries connection (long backup model)
For different UPS model, users are instructed to configure different battery voltage
as below table. More or less units are forbidden, or else something abnormal or
faulty will appear.
