easy Maxx JD3362 - Device Setup and Components; Parts List

31 EN
Parts List
No. Illustration Description Quantity Ø
1 Motor unit 1
Accessories to be fi tted onto the motor unit
2
Flexible shaft
for intricate work
1
3
Router compass
for cutting out circles (Ø 10 to 52 cm)
1
4
Edge trimming unit
for setting the cutting depth and guiding the
device
1
5
Handle
for easier guidance of the device
1
6
Open-jaw wrench, large 1
7
Collet
(already mounted if applicable)
16.4 mm
8
Collet 1 4 mm
9
Collet 1 3.2 mm
10
Chuck for mounting the fl exible shaft 12.8 mm
11 Cutter 1 6.4 mm
12
Cutter 1 4 mm
13
Cutter 1 3.2 mm
Accessories to be fi tted onto the fl exible shaft
14
Open-jaw wrench/screwdriver, small 1
15
Stone
for manual polishing and for sharpening
and cleaning of the attachments
1
16
Abrasive sleeves 5 15 mm
