Edge trimming unit
h Height-adjusting screw
i Clamping ring
j Quick clamping lever
k Spacer
Handle
l Grip
m Clamping ring
n Quick clamping lever
Flexible shaft
o Clamping nut
p Clamping ring
q Quick clamping lever
r Grip
Router compass
s Grip
t Adjusting screw
u Scale
v Square plastic disc
w Round plastic disc
x Centring pin
Before Initial Use
CAUTION!
• Danger of suffocation from plastic fi lms and bags! Keep children and animals away
from the packaging material.
1. Unpack the items supplied and check them for completeness (see the "Parts List"
chapter) and transport damage. If any parts of the items supplied are missing or
damaged, do not use the device(!), but contact our customer service department.
2. Before using the device, remove all packaging materials which are used to protect
the device during transport or for advertising.
3. Familiarise yourself with all of the features and functions of the device.
