-8-
4. Panel Description
The display panel of 1K/1KXL/2K/2KXL/3K/3KXL is the same, which is
shown as below:
■ Figure 4.1 The Display Panel
4.1 Button
Switch Function
ON/Silence
Button
Turn on UPS system:
By pressing the ON-Button continuously for more than 1 second the
UPS system is turned on.
Deactivate acoustic alarm:
By pressing this Button, an acoustic alarm and LCD blue
background blinking can be deactivated in the battery mode.
By short touch this Button all acoustic alarms can be deactivated in
all modes.
Do the battery test:
By pressing this Button the UPS can do the battery test in the Line
mode or ECO mode or CVCF mode.
OFF
Button
When mains power is normal, the UPS system switches to No
output or Bypass mode by pressing OFF-Button, and the inverter is
off. At this moment, if Bypass is enabled, then the output sockets are
supplied with voltage via the bypass if the mains power is available.
Deactivate acoustic alarm:
To Next Page
