-14-
(2) UPS Output Connection
The output sockets and types of the UPS are shown below:
Model No. Output Socket (number & type)
9E-IN 1K
4 IEC type
9E-IN 2K
4 IEC type+1 terminal
9E-IN 3K
4 IEC type +1 terminal
9E-IN 1KXL
3 IEC type
9E-IN 2KXL
3 IEC type +1 terminal
9E-IN 3KXL
3 IEC type +1 terminal
The wiring procedure is shown as the Figure 5.1:
a) Remove the small cover of the terminal block
b) Use 12AWG wires(recommended) for wiring configuration, the
suggested tighten force is 5KgF.cm
c) Upon completion of the wiring configuration, please check whether
the wires are securely affixed
d) Put the small cover back to the rear panel
(3) Battery Input Connection for long backup time model
When connecting the external batteries it’s recommended to pay
attention to these following items:
★ Use the battery pack with voltage:
36VDC for 1KXL (3 pcs of 12V batteries);
72VDC for 2KXL, (6 pcs of 12V batteries);
96VDC for 3KXL (8 pcs of 12V batteries).
Note: Connection of batteries more than or less than required
will cause abnormality or permanent damage.
★ One hard wiring type battery terminal on the rear panel is
used for connecting the battery pack(For 1KXL/2KXL).
★ The battery connection procedure is very important. Any
incompliance may result in the risk of electric shock.
Therefore, the following steps must be strictly complied with.
★ If there is a battery breaker then turn it off first. Then connect
the battery cable to the Standard type battery connector on
the real panel (for 3KXL).
