OPTIM OPTIM
DIGITRIP RMS Type 510 610 810 910 750 1050
Instruction Leaflet No. I.L. 29-885 I.L. 29-886 I.L. 29-888 I.L. 29-889 I.L. 29C891 I.L. 29C891
Potential Transformer Module X X X
PTM Disconnect Plug for Dielectric
Testing of Circuit Breaker X X X
Energy Monitoring: Parameters:
System Power Factor LED m X
Peak Demand LED X X
Peak Demand Reset l l
Present Demand LED X X
Reverse Power Flow l l
“NPOW” Message X X
Energy Consumption LED X X
Forward Energy m m
Reverse Energy m m
Energy Reset m m
INCOM/IMPACC - X X X
(Integrated Communications)
Address Register q q
Baud Rate Register q q
Transmittable Parameters:
Individual Phase Currents l l
Ground Currents l o l o o o
Breaker Status:
High Load “HILD” l l
Open/Closed/Tripped l l
Mode of Trip:
Instantaneous “INST” l l
DIScriminator “DISC” l l
Short Time Delay “SDT” l l
Ground Fault “GNDT” l o l o
Long Delay “LDT” l l
Overtemperature “TEMP” l l
External Trip “EXTT” l l
Long Time Delay Pickup “LDPU” l l
Over Range Trip “ORNG” l l
Information:
Normal “NORM” l l
Protection Settings m m
Time Stamp Trip Event m m
Trip Event Counter m m
Rating Plug Problem “PLUG” l l
Communication Failure “NRES” k n k n
Control:
INCOM/IMPACC Trip (Open) Command m m m m
INCOM/IMPACC Close Command m p m p m p m p
INCOM/IMPACC Trip Reset Command m m m m
Energy Monitoring
q Configuration of address is programmed on face of unit with pushbuttons.
r Optional APM is available separately.
s Supplied if INST protection is omitted.
Disabled when “NPOW” message is disabled.
Can be disabled with jumper on circuit board.
Via OPTIMizer – test and configuration of address and baud rate.
BIM (Breaker Interface Module) or direct to host computer.
Supplied only when trip unit is equipped with ground fault alarm.
Transmittable DataControl
Effective July 2010
Instructional Leaflet IL8700C39-04
8
EATON CORPORATION www.eaton.com
