Technical Data
Parameters Range, characteristics
Supply voltage DC 18 ... 30 V, residual ripple < 10%
Solenoid systems selection 0.8 A / 1.1A / 1.3 A / 1.6 A / 2.4 A / 2.7 A / 3.5 A
Power input Max. 50 VA
Applicable fuse (quick) 3.15 A
Auxiliary voltage ± 10 V, max. load 10 mA.
Control voltage for external
recallable set point
24 V ±10%, residual ripple ≤ 10%
current input ≤ 20mA each
Ambient temperature 0 °C ... 50 °C(other range on request)
Storage temperature - 20 °C ... 60 ° C
Plug connection DIN 41 612, 48 pol. form F gold plated
EMC
Protection Burst on wires as per EN 61000-4-4
HF-Field as per EN 61000-4-3
ESD as per EN 61000-4-2
Emissions Emissions depending on power as per EN 50011
Radiated emissions as per EN 55011
Additional Certifications
Vibration All directions as per DIN EN 60068-2-6
Shock All directions as per DIN EN 60068-2-27
Dimensions
Front panel/ PCB 50,5 x 128,4 mm; 10 TE / 3 HE / 100 x 160 mm Euro format
Input signals
Analogue set values
1 input, differential 14 Bit resolution, 0 ... ± 10 V
1 input, single ended 14 Bit resolution, 0...± 10 V
1 input, single ended 14 Bit resolution, 0 or 4...20 mA
Analogue feedback
(sensor input)
1 input, 14 Bit resolution, 0... ± 12 V, 0...20 mA / 4...20 mA, Offset: 3..10
V, Gain: ca. 0 ...14 (R=100 Ohm)
1 input, 14 Bit resolution, 0... ± 10 V
Digital inputs
8 inputs, voltage level 0 V / 24 V 10 mA
(Set point S1.01 ... S1.04, ENABLE, RAMP 0 , SIGN + , SIGN -)
