Startup Wizard
In the Startup Wizard , you will be prompted for essential
information needed by the drive so that it can start
controlling your process. In the Wizard, you will need the
following keypad buttons:
Left/Right arrows. Use these to easily move
between digits and decimals.
Up/Down arrows. Use these to move between
options in menu and to change value.
OK button. Confirm selection with this button.
Back/Reset button. Pressing this button, you can
return to the previous question in the Wizard. If
pressed at the first question, the Startup Wizard will
be cancelled.
Once you have connected power to your Eaton H-Max
frequency converter, follow these instructions to easily set
up your drive.
Note

These questions appear if battery is installed.
Now the Startup Wizard is done.
The Startup Wizard can be re-initiated by pressing and
holding the back/reset button for two seconds. The Startup
Wizard will appear upon next power up.
1
Run Startup Wizard Yes
No
2
Language Select Depends on language package
3
Daylight Saving

Russia
US
EU
OFF
4
Time

hh:mm:ss
5
Day

dd.mm.
6
Year

yyyy
OK
BACK
RESET
7
Application H-Max Standard
PID
Multi-Pump
8
Bypass Enabled
Disabled
9
Motor Nominal Current Min: 0.26A
Max: Drive Dependent
10
Motor Nominal Voltage Min: 180.0V
Max: 690.0V
11
Motor Nominal Frequency Min: 8 Hz
Max: 320 Hz
12
Motor Nominal Speed Min: 24 RPM
Max: 19200 RPM
13
Min Frequency Min: 0 Hz
Max: 60 Hz
14
Max Frequency Min: 12 Hz
Max: 320 Hz
15
Accel Time 1 Min: 0.1s
Max: 3000s
16
Decel Time 1 Min: 0.1s
Max: 3000s
17
StartSourceHand Keypad
FieldbusCTRL
I/O Three-Wire
I/O Terminal
18
StartSourceAuto I/O Terminal
Keypad
FieldbusCTRL
I/O Three-Wire
19
SpeedSetptHand Keypad Ref
P1D1 Activated
AI1 + AI2
AI2
AI1
Fieldbus
20
SpeedSetptAuto PID1 Activated
AI1 + AI2
AI2
AI1
Fieldbus
Keypad Ref
