Eaton HFX Series User Manual

EATON HFX Product Family Installation and Operation Manual E-ELCL-II002-E2 July 201910
Input Type Frequency, Ch 3-8, Analog, Pull-up or Pull-down Resistor (Software Congurable)
Analog Input Resolution 9 bits
Accuracy +/- 2% FS
Measuring Range 0…5V
Input Type Variable reluctance (Software congurable)
Maximum Input Frequency Ch 1-2 (FREQ) (0-5 V square or sine wave) 0Hz...25kHz* Note: maximum aggregate is 200 kHz. Note: phase and duty cycle are not supported by
these inputs minimum detectable pulse duration is 20 μsec
Switch-on Level Selectable as 2.2 V or self-adaptive (input device changes voltage with frequency)
Switch-off Level Selectable as 0.0 V or 1.0 V
Input Type Variable Reluctance, Ch 1-2, Analog (Software Congurable)
Analog Input Resolution 9 bits
Accuracy +/- 15% FS
Measuring Range 0…5V
Output Type High Side (Software congurable)
Max Amperage 2A
Diagnostics Open/Short circuit protection
Output Type Low/High side, H-Bridge (Software congurable)
Max Amperage 4A
Diagnostics Open/Short circuit protection
Output Type PWMi, High side (Software congurable)
Max Amperage 2A
Diagnostics Open/Short Circuit Protection
PWM Frequency 50 – 2 kHz
Dither Frequency Congurable 1 - 500 Hz
Dither Amplitude Congurable 1 - 100%
Control Range 0.05 - 2 A
Control Resolution 1 mA
Fly Back Protection Integrated
Duty Cycle Resolution .01% @ 250 Hz
Output Type PWMi, High Side (Software congurable)
Max Amperage 4A
Diagnostics Open/Short circuit protection
PWM Frequency 50 – 2 kHz
Dither Frequency Congurable 1 - 500 Hz
Dither Amplitude Congurable 1 - 100%
Control Range 0.05 - 4 A
Control Resolution 1.5 mA
Fly Back Protection Integrated
Duty Cycle Resolution .01% @ 250H
Connector Manufacturer Deutsch Inc.
Model DRC23-40PA & DRC23-40PB
Contact Surface Nickel plated
A and B Connector Assembly Parts List Mating connector: P/N: DRC26-40SA & DRC26-40SB, size 20 solid contacts P/N: 0462-201-20141
intended for 20AWG wire, P/N: 0462-005-20141 intended for 16-18 AWG wire, size 20 stamped and
formed contacts P/N: 1062-20-0122 (nickel plated), and sealing plug P/N: 0413-204-2005
A and B Connector Tooling Manufacturer Deutsch
A and B Connector Hand Tool Part Number Solid contacts: Service crimper: HST-1561 Production crimper(ratcheting): HDT-48-00
Stamped contacts: DTT-20-00
A and B Connector Contact Removal Tool P/N: 0411-240-2005
P Connector Assembly Parts List Mating connector DT06-6S-EP06, size 16 solid contacts P/N 0462-201-16141
intended for 14-18AWG wire, size 16 stamped and formed contacts P/N 1062-16-0122(nickel plated),
wedge W6S-P012, sealing plug P/N 0413-217-1605
P Connector Tooling Manufacturer Deutsch
P Connector Hand Tool Part Number Solid contacts: Service crimper: HST-1561 Production crimper(ratcheting): HDT-48-00
Stamped contacts: DTT-16-00
HFX Product Family

Eaton HFX Series Specifications

General

Brand	Eaton
Model	HFX Series
Category	Controller
Language	English
