EATON HFX Product Family Installation and Operation Manual E-ELCL-II002-E2 July 2019 9
2.0 TECHNICAL SPECIFICATIONS
Eaton HFX Controllers
Dimensions 212.61mm L x 134.17mm W x 58.55mm H
Weight 43.2 ounces (1225 grams)
Storage Temperature Range -40 - +125 °C
Operating Temperature Range -40 - +105°C (USB use is limited to 85°C)
IP Rating IP67/IP69K
Operating Altitude 0-4000 m
Supply Voltage 6-32 VDC, Nominal operation @ 12 /24 VDC
Reverse Polarity Protection Integrated
Peak Supply Voltage 36 VDC
Maximum Current 48 A @ 85°C (40 A @ 105°C)
Idle Current 12/24 VDC 120 mA
Standby Current 12/24 VDC <3.5mA@12V, <2.5mA@24V
Ignition Pin (A16) Enable/Disable standby mode
CPU Type Renesas Super H 72546
Frequency 200 MHz
Bit Width 32 Bit
FPU Integrated on chip
Data Memory (RAM retain) (additional to cpu) 32 Kbyte
Flash (ROM program & data combined) 3.75 Mbyte
SRAM 256 Kbyte
EEPROM 128 Kbyte
CAN Specication 2.0A, 2.0B
CAN Baud Rates 50 kb/s,100 kb/s,125 kb/s,250 kb/s,500 kb/s,800 kb/s,1Mb/s
CAN Protocol CANOpen, SAE J1939
CAN CCP Default Node Address 0
CAN Default Baud Rate 250kb/s
USB Specication USB 2.0 (Note: 3.0 devices are compatible)
USB Baud Rates See below
USB Default Node Address N.A.
USB Default Baud Rate 1.5 Mb/s
Number of Sensor Supplies 2
Sensor Supply Output Voltage 5 VDC or 10 VDC (congurable)
Sensor Supply Maximum Current 200 mA @ 5VDC, 100 mA @ 10V per supply
Analog Input Resolution 12 bits, *10 bits
Accuracy +/- 1 % FS
Measuring Ranges 0...5 V, 0...10 V*, 0...32 V, 0...20 mA
Short Circuit Protection Integrated
Open Circuit Detection Dependent upon selectable termination
Input Sampling Frequency 1 kHz
Input Type Digital Low/High Side (Software congurable)
Maximum Input Frequency 200 Hz
Switch-on Level Software congurable
Switch-off Level Software congurable
Input Type Frequency, Digital Low/High side, (Software congurable)
Maximum Input Frequency Ch 3-8 (FREQ) (0-5 V square wave) Ch 3-8 0 Hz...50 kHz* in Frequency mode. Note: maximum aggregate is 200 kHz,
Minimum detectable pulse duration is 20 μsec
Maximum Input Frequency Ch 3-8 (Dig)
Switch-on Level (design review required) Standard switch on at 3.0 V (this can be changed in hardware)
Switch-off Level (design review required) Standard switch off at 2.0 V (this can be changed in hardware)
