EATON HFX Product Family Installation and Operation Manual E-ELCL-II002-E2 July 201912
The table below represents an I/O overview of the various HFX controller models.
HFX48m HFX32m HFX20m HFX12m
Controller Model (24 I/O) (16 I/O) (10 I/O) (6 I/O)
Total Outputs 24 16 10 6
Total 2 A channels 16 10 6 4
Number of channels supporting function
PWM 16 10 6 4
PWMi 16 10 6 4
High Side output 16 10 6 4
Total 4 A channels 8 6 4 2
Number of channels supporting function
PWM 8 6 4 2
PWMi 8 6 4 2
High Side output 8 6 4 2
Low Side output 8 6 4 2
H-Bridge pair 4 3 2 1
HFX48m HFX32m HFX20m HFX12m
Controller Model (24 I/O) (16 I/O) (10 I/O) (6 I/O)
Total Inputs 24 16 10 6
Total frequency channels 8 6 4 2
Number of channels supporting function
High frequency 8 6 4 2
Variable reluctance 2 2 2 2
High Side input 8 6 4 2
Low Side input 8 6 4 2
Total analog channels 16 10 6 4
Number of channels supporting function
0 - 5 V input 16 10 6 4
0 - 10 V input 16 10 6 4
0 - 32 V input 16 10 6 4
4 - 20 mA input 16 10 6 4
High Side input 16 10 6 4
Low Side input 16 10 6 4
Thermistor 16 10 6 4
