Eaton INV-4815E - Wire Size Tables

Matrix Telecom Inverter System
16
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D February 2010
Wire Size Tables
IMPORTANT: Use the following table as a guide only. Ensure that the installation complies
with the local wiring rules.
Recommend Wire Size Versus Current - 1kVA Inverter modules (see Notes)
Shelves Input
current
Max.
110Vac
output
current
Max.
230Vac
output
current
Max.
Min. size of dc
input wire
Max.
Min. size of
110Vac O/P
wire Max.
Min. size of
230Vac O/P
wire Max.
1 46.0A 18.2A 8.7A #8 AWG
10mm
2
#14 AWG
2.5mm
2
#16 AWG
1.5mm
2
2 92.0A 36.4A 17.4A #4 AWG
25mm
2
#10 AWG
6mm
2
#14 AWG
2.5mm
2
3 138.0A 54.5A 26.1A #8 AWG
10mm
2
#10 AWG
6mm
2
4 184.0A 72.7A 34.8A #6 AWG
16mm
2
#10 AWG
6mm
2
5 230.0A 90.9A 43.5A #4 AWG
25mm
2
#8 AWG
10mm
2
6 276.0A 109.1A 52.2A
Connect to
shelves in
groups of up to
two. See details
on page 19
.
#2 AWG
35mm
2
#8 AWG
10mm
2
Recommend Wire Size Versus Current - 1.5kVA Inverter modules (see Notes)
Shelves Input
current
Max.
110Vac
output
current
Max.
230Vac
output
current
Max.
Min. size of dc
input wire
Max.
Min. size of
110Vac O/P
wire Max.
Min. size of
230VA O/P
wire Max.
1 69.0A 27.3A 13.0A #6 AWG
16mm
2
#12 AWG
4mm
2
#16 AWG
1.5mm
2
2 137.9A 54.5A 26.1A #2 AWG
35mm
2
#8 AWG
10mm
2
#10 AWG
6mm
2
3 206.9A 81.8A 39.1A #6 AWG
16mm
2
#10 AWG
6mm
2
4 275.9A 109.1A 52.2A #2 AWG
35mm
2
#8 AWG
10mm
2
5 344.8A 136.4A 65.2A #2 AWG
35mm
2
#6 AWG
16mm
2
6 413.8A 163.6A 78.3A
Connect to
shelves in
groups of up to
two. See details
on page 19
.
#2 AWG
35mm
2
#6 AWG
16mm
2
