Figure 16. Typical IZM63 and IZM99 Standard Frame Fixed Circuit Breaker Features (Front and Rear Views)
1–Baffled Arc Chute Cover
2–Secondary Contact Connector
3–Faceplate (front cover)
4–Integral Lifting Handle
5–Fixed Vertical Primary Terminals
(with optional vertical adapter)
6–Arc Chamber
7–Mounting Foot
8–Circuit Breaker Nameplate
9–Phase Identification Labels
10–Tripper Bar
1
4
10
7
8
3
1
10
7
2
4
9
9
9
9
5
6
