Eaton IZM32 - Figure 64. Drawout Cassette Features (Front and Rear Views)

41
10/09 AWB1230-1605
Effective October 2009
Operation and maintenance of
IZM low voltage air circuit breakers
MOELLER www.moeller.net/de/support
Figure 64. Drawout Cassette Features (Front and Rear Views)
Front View
Rear View
1. Extension Rails
2. Extension Rail Cutout
3. Secondary Plug-in Connectors
4. Secondary Terminal Blocks
5. Arc Hood
6. Optional Cell (TOC) Switch
7. Optional Key Interlock
8. Earthing Bar
9. Open Safety Shutters
10. Primary Terminals
4
3
6
7
2
1
8
9
2
1
4
5
6
10
7
