Main Display - LMR Plus Fire Pump Controllers
LMR
PLUS
PLUS
MD05805096K/D
Main Display
LMR PLUS Electric Fire Pump Controllers
Main Display
NOTES:
1. Refer to the LMR Plus technical manual for detail and setup
information, as well as programming and custom labelling for
Programmable LED # 1 and Programmable LED # 2.
NOTE: As of January 1, 2009 - All Limited Service Controllers will not carry FM Approval.
June 2011
N. Y. C.
APPROVED
POWER ON
PUMP RUNNING
LOCAL START
REMOTE START
DELUGE VALVE
EMERGENCY START
INTERLOCK ON
LOW PRESSURE
AUTO SHUTDOWN ENABLED
PHASE REVERSAL
PHASE FAILURE
FAIL TO START
UNDERVOLTAGE
OVERVOLTAGE
LOW ROOM TEMPERATURE
LOCKED ROTOR TRIP
LOW SUCTION PRESSURE
SOURCE 2 DISCONNECTED
LMR
PLUS
ACK.
MENU
SAVE/EXIT
DATA
PRINT
LAMP
TEST
RESET
MOTOR
TEST
SILENCE
ALARM
99-5816-01
U.B.C and C.B.C
Must Be Installed Per Applicable Code
and Manufacturers Recommendations
SEISMIC QUALIFIED
