Step 4 — Parameter Groups & Default Values (Continued)
80 — KEYPAD/DISPLAY (Continued)
Modbus Groups Description Range Default
User
Settings
0602H 80.03 Manufacturer Model
Information
08: MVX001#0-4
(460V 3ph 1 hp)
##
09: MVX002#0-4
(460V 3ph 2 hp)
10: MVX003#0-4
(460V 3ph 3 hp)
11: MVX005#0-4
(460V 3ph 5 hp)
12: MVX007#0-4
(460V 3ph 7-1/2 hp)
13: MVX010#0-4
(460V 3ph 10 hp)
14 – 19: Reserved
20: MVXF25#0-1
(115V 1ph 1/4 hp)
21: MVXF50#0-1
(115V 1ph 1/2 hp)
22: MVX001#0-1
(115V 1ph 1 hp)
23 – 49: Reserved
50: MVX001#0-5
(575V 3ph 1 hp)
51: MVX002#0-5
(575V 3ph 2 hp)
52: MVX003#0-5
(575V 3ph 3 hp)
53: MVX005#0-5
(575V 3ph 5 hp)
54: MVX007#0-5
(575V 3ph 7-1/2 hp)
55: MVX010#0-5
(575V 3ph 10 hp)
0603H 80.04 Present Fault Record 00: No Fault occurred 00
0604H 80.05 Second Most Recent
Fault Record
01: Over-current (oc) 00
0605H 80.06 Third Most Recent
Fault Record
02: Over-voltage (ov) 00
03: Overheat (oH)
04: Overload (oL)
05: Overload 1 (oL1)
06: Overload 2 (oL2)
07: External Fault (EF)
08: CPU Failure 1 (CF1)
09: CPU Failure 2 (CF2)
10: CPU Failure 3 (CF3)
11: Hardware Protection Failure
(hpF)
12: Over-current During Accel (OCA)
13: Over-current During Accel (OCd)
14: Over-current During Steady
State (OCn)
15:Ground Fault or Fuse Failure
(GFF)
16: Reserved
17: 3 Phase Input Power Loss
18: External Pause Function (bb)
19: Auto Adjust Accel/Decel Failure
(cFA)
20: Software Protection Code (codE)
