Eaton MVX9000 Series - Motor Control

MN04002001E
12
March 2006
Step 4 — Parameter Groups & Default Values (Continued)
50 — DRIVE CONTROL (Continued)
60 — MOTOR CONTROL
Modbus Groups Description Range Default
User
Settings
033BH 50.60 Second Source of
Operation Command
00: Operation determined by digital
keypad
03
01: Operation determined by
external control terminals, keypad
STOP is effective
02: Operation determined by
external control terminals, keypad
STOP is ineffective
03: Operation determined by RS-485
interface, keypad STOP is effective
04: Operation determined by RS-485
interface, keypad STOP is ineffective
033CH 50.61 HOA and LOC/REM
Stop Methods
00: Ramp to Stop 01
01: Coast to Stop
033DH 50.62 OV Fault During Stop
State
00: Disable 00
01: Enable
Modbus Groups Description Range Default
User
Settings
0400H 60.01 Motor Rated Current 30 to 120% FLA
0401H 60.02 Motor No-Load
Current
00 to 99% 0.4* FLA
0402H 60.03 Motor Auto Tuning 00: Disable 00
01: DC test
02: DC test and no load test
0403H 60.04 Motor’s Stator
Resistance
(calculated via auto
tune or entered
manually)
00 to 65535 m Ohms 00
0404H 60.05 DC Braking Current
Level
00 to 100% 00
0405H 60.06 DC Braking Time
upon Start-up
0.0 to 5.0 sec 0.0
0406H 60.07 DC Braking Time
upon Stopping
0.0 to 25.0 sec 0.0
0407H 60.08 Frequency-point for
DC Braking
0.0 to 60.0 Hz 0.0
0408H 60.09 Torque
Compensation
00 to 10 00
0409H 60.10 Slip Compensation 0.00 to 10.00 0.0
040AH 60.11 PWM Carrier
Frequency
115V/230V/460V: 1 to 15 KHz 9
575V: 1 to 10 KHz 6
