APP TECH DATA VOLUME ONE
EASTERN ACOUSTIC WORKS, INC. One Main Street, Whitinsville, MA 01588 • TEL: (508) - 234 - 6158 • FAX: (508) - 234 -
8251
Volume I: Release 1.1 APP Page 18
3.2 MECHANICAL DRAWINGS
3.2.1 KF300
I P & KF300 IX P I NSTALLATION C ONFIGURATION
FRONT
SIDE BACK
3.5
KF300ixP
TOP/BOTTOM TOP/BOTTOM
23.5
2.0
14.75
14.75
14.0
27.5
6.8
1.375
24.75
9.563
2.0
8.75
3.875
1.375
6.81311.25
OPTIONAL
MO UNTING POI NTS
(BEHIND LID)
NOTE:
1. 1/2" DIAMETER HOLE THROUGH CABINET
BACKED WITH 3/8 X 16 THREADED NUT
SPOT WELDED ON TO 1/8" THICK STEEL
L-SHAPE PLATE.
2. WEIGHT 80 Ibs (36.4 Kg)
10.37
10°
2.5
9.844
9.128
7.375
4.781
3.122
KF300iP
MOUNTING
POI NTS
