APP TECH DATA VOLUME ONE
EASTERN ACOUSTIC WORKS, INC. One Main Street, Whitinsville, MA 01588 • TEL: (508) - 234 - 6158 • FAX: (508) - 234 -
8251
Volume I: Release 1.1 APP Page 19
3.2 MECHANICAL DRAWINGS
3.2.2 KF300
I R & KF300 IX R P ORTABLE C ONFIGURATION
BACKFRONT
KF300iR
KF300ixR
MOUNTING
POI NTS
BOTTOM
TOP/BOTTOM
NOTE:
1. MOUNTING POI NTS ARE AIRCARGO
20050 TYPE SINGLE STUD BACKED
WITH 1/4" THICK PLATE.
2. WEIGHT 80 IBS (36.4 KG)
TOP/BOTTOM
SIDE
1.375
10°
3.875
1.375
9.563
14.0
6.813
7.375
3.122
9.844
9.128
7.375
6.75
27.5 27.5
14.75
6.8
8.75
24.75
4.781
2.5
10.37
14.75
Ø 2.0
4.781
8.0
