APP TECH DATA VOLUME ONE
EASTERN ACOUSTIC WORKS, INC. One Main Street, Whitinsville, MA 01588 • TEL: (508) - 234 - 6158 • FAX: (508) - 234 -
8251
Volume I: Release 1.1 APP Page 20
3.3 INPUT PANEL
3.3.1 KF300
I P I NSTALLATION C ONFIGURATION

UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS ARE IN INCHES

TOLERANCES ON INCHES
.XX +/- .015 .XXX +/- .005

TOLERANCES ON MILLIMETERS
0.0 +/- .38mm 0.00 +/- .13mm

ANGLES FRACTIONS
+/- 1/2° +/- 1/32
 THIS DRAWING IS THE PROPERTY  OF EAW AND SHALL NOT BE  REPRODUCED, COPIED OR USED AS  THE BASIS FOR MANUFACTURE OR  SALE OFAPPARATUS WITHOUT  WRITTEN AUTHORIZATION
APPROVAL
PRELIMINARY
DRAWN:
FINAL
CHECKED:
CHECKED:
ENG:
ENG:
RELEASED:
DATE DATE
APPROVED FOR TOOLING: DATE:
EAW WHITINSVILLE, MA. 01588
USED ON:
SCALE: 1:1.25
SHEET 1 OF 1
REV: A
SIZE: A
NUMBER:
INPUT PLATE
KF300iP
LOW INPUT
HIGH INPUT
KF-300i

N0.
SOUND REINFORCEMENT SYSTEM
+
+-- --
LF
MF/HF
MADE IN USA
HORN LEVEL
--3db
0db
NOTE:
CONNECTORS:
2 BLACK BANANAS
1 BLUE BANANA
1 RED BANANA
1 4-142 Y CINCH CONNECTOR
1 100WATT L-PAD

EASTERN ACOUSTIC WORKS
