Volume I: Release 1.1 APP Page 24
3.4 HANGING HARDWARE
3.4.1 2"
X 2" S TEEL L-P LATE
STEEL
1.25
.5
1.375
Ø .25
Ø .375
1.375
.625
1.0
.25
1.0
2.0
2.0
Ø .375
2" x 2" L-SHAPE STEEL PLATE
.125
NOTE:
1/2" DIAMETER HOLE THROUGH
CABINET
BACKED WITH 3/8 x 16 THREADED NUT
SPOT WELDED ONTO 1/8" THICK STEEL
L-SHAPE PLATE.
1.5
.75
1.25
BALTIC BIRCH
HARDWOOD
