Volume I: Release 1.1 APP Page 62
3.7 CCEP
TM
C ROSSOVER &
P
OWERING O PTIONS
3.7.2 MX200I-3 CCEP
TM
3.7.2.1 C ONFIGURATION D ATA
Date: 8/31/92 Part#:200003A Used With: KF300i
Designation Value PCB # Function Implementation
R1 1+2 not used
R2 127K 1+2 LF EQ +6.3 dB @ 60 Hz
R3 1+2 Parametric EQ
R4 1+2 Parametric EQ
R5 1+2 Parametric EQ
R6 0 ohms 1+2 Parametric EQ
R7 1+2 not used
R8 63.4K 1+2 dynamic HP f=25 Hz, Q=.707
R9 63.4K 1+2 dynamic HP f=25 Hz, Q=.707
R10 1+2 not used
R11 1+2 Parametric EQ
R12 0 ohms 1+2
R13 7.15K 1+2 LF EQ +6.3 dB @ 60 Hz
R1 1.0K 3+4 LF phase 100K/22 nF
R2 3+4 not used
R3 3+4 not used
R4 3+4 not used
R5 open 3+4 LF gain 0 dB
R6 open 3+4 LF gain 0 dB
R7 3+4 not used
R8 45.3K 3+4 fixed LF hi-pass f=25 Hz, Q=.707
R9 8.25K 3+4 HF gain -5.75 dB
R10 137K 3+4 LF threshold 1.0V
R11 90.9K 3+4 fixed LF hi-pass f=40 Hz, Q=.707
R12 1.74K 3+4 HF gain -5.75 dB
R13 140K 3+4 HF threshold 1.0 V
R14 3+4 not used
R15 3+4 not used
R16 3+4 not used
R17 3+4 not used
RN2,RN8 10K HF hi-pass 339 Hz (47 nF)
RN4,RN10 7.5K LF lo-pass 451 Hz (47 nF)
NOTES:
1) High Frequency EQ jumper: Pin 2
