3.6 KF300 I P ERFORMANCE D ATA
3.6.4 BEAMWIDTH VS. FREQUENCY
3.6.4.1 G
RAPHIC D ATA
B
K
270°
225°
180°
135°
1k Hz 2k 2.5k500100 200 5k 8 k 10k 16k
KF300i With MX300i-3 Beamwidth vs Frequency
1/3 Octave Bands - 6 dB Points
4k
90°
45°
0°
Horizontal
Vertical
