EBARA E-SPD+ MT 2200 - 4 - MODBUS PROTOCOL (INPUT REGISTERS)

384
4 - MODBUS PROTOCOL (INPUT REGISTERS)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
SOFTWARE VERSION H (CONTROL BOARD) (4 first chars)
SOFTWARE VERSION L (CONTROL BOARD) (4 last chars)
SOFTWARE VERSION H (POWER BOARD) (4 first chars)
SOFTWARE VERSION L (POWER BOARD) (4 last chars)
MAXIMUM MOTOR CURRENT (POWER BOARD)
STOP/AUTO
CURRENT SETPOINT
ACTUAL PRESSURE
ACTUAL TEMPERATURE
4-20mA INPUT 1
4-20mA INPUT 2
0-10V INPUT
PTC/NTC INPUT
DIGITAL INPUT 1
DIGITAL INPUT 2
DIGITAL INPUT 3
DIGITAL INPUT 4
RELAY 1 OUTPUT
RELAY 2 OUTPUT
EXPANSION BOARD CONNECTED
ALARM CODE (POWER BOARD)
MOTOR ACTUAL FREQUENCY
MOTOR ACTUAL CURRENT
POWER MODULE TEMPERATURE
CONTROL AMBIENT TEMPERATURE
ACTUAL MOTOR POWER
ACTUAL NETWORK POWER
POWER ON HOURS (MSB)
POWER ON HOURS (LSB)
OPERATING HOURS (MSB)
OPERATING HOURS (LSB)
START-UP NUMBER COUNTER (MSB)
START-UP NUMBER COUNTER (LSB)
ALARM F01 COUNTER
ALARM F02 COUNTER
ALARM F03 COUNTER
ALARM F04 COUNTER
HEX
HEX
HEX
HEX
0.1A
0.1Bar / PSI
0.1Bar / PSI
0.1ºC / 0.1ºF / ***
0.1mA
0.1mA
0.1V
0.1 kohm
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0.1Hz
0.1Hz
ºC
ºC
W
W
s
s
s
s
MODBUS ADRESS VALUE / PARAMETER UNITS
