P.41
PM10U
EBARA
CORPORATION
6.4 Dip Switch
Set the dipswitches to select the operating modes as shown in Table 6.4, 6.5 and 6.6.
Table 6.4 Dip Switch-A Settings
No. Mode Off On Factory
setting
1 Data Length 7bits 8bits ON
2 Monitor Cooling water and N2 Always Only during operation OFF
3 Buzzer Not used Use ON
4 Operation switched to Remote According to signal Automatically stop OFF
5 External start/stop signal Alternate (Level) Momentary (Pulse) OFF
6 ----- ----- ----- -----
7 Dilution N2 mode Standard mode Dilution N2-0 mode OFF
8 BP operation in Remote Automatic operation External signal input OFF
Table 6.5 Dip Switch-B Settings
No. Mode Off On Factory
setting
1 ----- ----- ----- -----
2 ----- ----- ----- -----
3 ----- ----- ----- -----
4 Pump N2 valve control* No Yes OFF
5 ----- ----- ----- -----
6 Remote Interface (IF) * Exclusive special IF No use / standard IF ON
7 Phase error monitoring Standard During starting only OFF
8 LCD screen initialize Carry out initialize Do not initialize OFF
* Optional
Table 6.6 Dip Switch-C Settings
No. Mode Off On Default
1 Outputs the pump N2 warning. Normal Open Normal Close Off
2 ------- ------- ------- -------
3 Outputs backpress. warning. * Normal Open Normal Close Off
4 ------- ------- ------- -------
5 ------- ------- ------- -------
6 Valve ON/OFF control * Not used Used Off
7 The output of a valve state * Not used Used Off
8 ------- ------- ------- -------
* Optional
DIP SW-A. No.1 In case of observing pump running status with RS232C
communication port, Data Length can be selected out of
7bits and 8bits.
