Eberspächer Easystart Remote + - CIRCUIT DIAGRAM; Connection Diagram for Hydronic Heaters

VEHICLE HEATERS – TECHNICAL DOCUMENTATION | 19
CIRCUIT DIAGRAM
EasyStart Remote+ connection to Hydronic, Hydronic II, Hydronic II C, Hydronic II Comfort,
Hydronic M II
* Hydronic MII 0.75
X:58
Light (+)
X:15
Ign (+)
-E5
1
-XB12
2
12
3
4
5
6
7
8
9
10
11
-H2
0,5* RD
0,22 RDYE
0,5* BUWH
0,22 BNWH
0,22 GY
0,22 BNYE
-W2
0,5* BN
Θ
-B8
0,22 BN
c
-XB12
22 1000 34 97 22
-B8 Room temperature sensor
-E5 EasyStart Remote
+
radio remote control
-H2 Button
-W2 Antenna
c to the heater
CABLE COLOURS
RD red GY grey BK black
BU blue YE yellow GN green
WH white VT violet BN brown
5 CIRCUIT DIAGRAM
