2 | VEHICLE HEATERS – TECHNICAL DOCUMENTATION
CONTENTS
CHAPTER CHAPTER TITLE PAGE
CHAPTER CONTENTS
1 INTRODUCTION
Please read first 4
General information / safety instructions 4
Intended use 5
VENTILATION operating mode 5
Technical data 6
Scope of supply 6
Sketch of EasyStart Remote
+
scope of supply 7
2 INSTALLATION
Installation 8
– Install stationary unit 8
– Install button 8
– Installing the room temperature sensor 8
Connecting the connector housing to the stationary unit 8
Sketch of EasyStart Remote
+
installation 9
Connecting the antenna 10
Minimum height of the antenna 10
Antenna dimensions 10
3 INITIAL STARTUP
Carry out the initial startup 11
Teach an additional mobile unit 12
Opening the vehicle workshop menu 13
– Selecting the temperature units –
Item 2: 13
