6 | VEHICLE HEATERS – TECHNICAL DOCUMENTATION
TECHNICAL DATA
Mobil unit:
Frequency: 433.166 MHz 434.6 MHz
Operating voltage 3 V (battery) CR 2430
Dimensions 66 x 41 x 15.7 mm
Operating temperature –20 °C to +60 °C
Storage temperature –40 °C to +85 °C
LCD ambient temperature The display becomes sluggish in tem-
peratures below –10 °C, i.e. the flashing
sequence of the symbols is somewhat
slower, the contrast becomes weaker above
+70 °C.
Stationary unit
Frequency 434.6 MHz
Operating voltage 12 V / 24 V
Dimensions 76 x 76 x 29 mm
Operating temperature / storage temperature –40 °C to +85 °C
Antenna connection Via coded SMB connector.
SCOPE OF SUPPLY
Order No. 22 1000 34 17 00 (Sketch see page 6).
No. in sketch Quantity Designation
1 1 Mobile unit
2 1 Stationary unit
3 1 Antenna
4 1 Button
5 1 Room temperature sensor
6 2 Self-tapping screws B3.9 x 19 for stationary unit
7 1 Self-tapping screws B2.9 x 19 for temperature sensor
8 1 Bush housing
9 1 Contact locking device
10 5 Contacts
11 1 Battery
12 1 Quick start guide
13 1 Installation instructions
Sketch of scope of supply see page 7
1 INTRODUCTION
