33
8.2 Engine
Perform the following steps to protect the cylinder, piston ring, etc.
from corrosion.
1. Remove the spark plug, pour about one tablespoon of SAE 10W-30
into the spark plug hole and reinstall the spark plug. Recoil start the
engine by turning over several times (with 3 in 1 switch knob off) to
coat the cylinder walls with oil.
2. Pull the recoil starter until you feel compression. Then stop pulling.
(This prevents the cylinder and valves from rusting).
3. Clean exterior of the generator. Store the generator in a dry,
well-ventilated place, with the cover placed over it. Lay the
engine vertically.
9. TROUBLESHOOTING
9.1 Engine won’t start
1. Fuel systems
· No gasoline in the fire chamber…Supply gasoline.
· Fuel in tank….Supply fuel.
Fuel in tank
· Clogged fuel filter …. Clean fuel filter.
· Clogged carburetor…. Clean carburetor.
2. Engine oil system
· Oil level is low…. Add engine oil.
3 . Electrical systems
· Put the 1 in 3 switch to “CHOKE” and pull the recoil starter …
Poor spark.
· Spark plug dirty with carbon or wet … Remove carbon or wipe spark
plug dry.
· Faulty ignition system … consult our company franchised dealer.
Inverter Generator Owner's Manual
Parameters
Parameters
Model No.
Generator
Type
Inverter
Rated frequency /Hz
Rated voltage /V
Max. output power /kW
Rated output power /kW
Power factor
AC output quality
THD/%
DC Output/ V-A
1.8
1.6
1.0
ISO8528 G2
≤5
63.5
12-8.3
Overload
Protect
DC
AC
Non-fuse Protector
Control by inverter overload
protect program
Engine
Engine
148F
Engine type
Single cylinder, 4-Stroke,
forced air cooling, OHV
Displacement/cc
79
Fuel type
Unleaded Gasoline
Fuel capacity/L
4.0
Continue Running
Time (at rated power) / h
4.0
Fuel Tank Capacity/L
0.35
Spark Model No.
Starting mode
Length×Width×Height/mm
499×285×455
Net weight/kg
21
Generator
set
E6TC/E6RTC
2000i
50/60/50
110/120/230
Noise Level dB/LpA/LwA/K 4m
(3/4 load)
Only 230V 50Hz with data meter product is GS certificated
.
Inverter Generator Owner's Manual
Troubleshooting
Troubleshooting
Recoil start
Max oil level
Min oil level
GENERATOR WON'T PRODUCE POWER
Safety device (DC protector) to “OFF”…. Press the DC protector
to “ON”.
The AC pilot light Green go off …. Stop the engine, and then restart.
（）
ENGINE CAN'T START
1. Fuel systems
No gasoline in the fire chamber.
No fuel in the fuel tank…add fuel.
Fuel in tank.
Clogged fuel filter …. Clean fuel
filter.
Clogged carburetor…. Clean
carburetor.
2. Engine oil system
Oil level is low…. Add engine oil.
3. Electrical systems
Put the 1 in 3 switch to “CHOKE”
and pull the recoil starter…Poor
spark.
Spark plug dirty with carbon or
wet…. Remove carbon or wipe
spark plug dry.
Faulty ignition system…. Consult
a dealer.franchised
36 37
Inverter Generator Owner's Manual
Parameters
Parameters
Model No.
Generator
Type
Inverter
Rated frequency /Hz
Rated voltage /V
Max. output power /kW
Rated output power /kW
Power factor
AC output quality
THD/%
DC Output/ V-A
1.8
1.6
1.0
ISO8528 G2
≤5
63.5
12-8.3
Overload
Protect
DC
AC
Non-fuse Protector
Control by inverter overload
protect program
Engine
Engine
148F
Engine type
Single cylinder, 4-Stroke,
forced air cooling, OHV
Displacement/cc
79
Fuel type
Unleaded Gasoline
Fuel capacity/L
4.0
Continue Running
Time (at rated power) / h
4.0
Fuel Tank Capacity/L
0.35
Spark Model No.
Starting mode
Length×Width×Height/mm
499×285×455
Net weight/kg
21
Generator
set
E6TC/E6RTC
2000i
50/60/50
110/120/230
Noise Level dB/LpA/LwA/K 4m
(3/4 load)
Only 230V 50Hz with data meter product is GS certificated
.
Inverter Generator Owner's Manual
Troubleshooting
Troubleshooting
Recoil start
Max oil level
Min oil level
GENERATOR WON'T PRODUCE POWER
Safety device (DC protector) to “OFF”…. Press the DC protector
to “ON”.
The AC pilot light Green go off …. Stop the engine, and then restart.
（）
ENGINE CAN'T START
1. Fuel systems
No gasoline in the fire chamber.
No fuel in the fuel tank…add fuel.
Fuel in tank.
Clogged fuel filter …. Clean fuel
filter.
Clogged carburetor…. Clean
carburetor.
2. Engine oil system
Oil level is low…. Add engine oil.
3. Electrical systems
Put the 1 in 3 switch to “CHOKE”
and pull the recoil starter…Poor
spark.
Spark plug dirty with carbon or
wet…. Remove carbon or wipe
spark plug dry.
Faulty ignition system…. Consult
a dealer.franchised
36 37
Inverter Generator Owner's Manual
Parameters
Parameters
Model No.
Generator
Type
Inverter
Rated frequency /Hz
Rated voltage /V
Max. output power /kW
Rated output power /kW
Power factor
AC output quality
THD/%
DC Output/ V-A
1.8
1.6
1.0
ISO8528 G2
≤5
63.5
12-8.3
Overload
Protect
DC
AC
Non-fuse Protector
Control by inverter overload
protect program
Engine
Engine
148F
Engine type
Single cylinder, 4-Stroke,
forced air cooling, OHV
Displacement/cc
79
Fuel type
Unleaded Gasoline
Fuel capacity/L
4.0
Continue Running
Time (at rated power) / h
4.0
Fuel Tank Capacity/L
0.35
Spark Model No.
Starting mode
Length×Width×Height/mm
499×285×455
Net weight/kg
21
Generator
set
E6TC/E6RTC
2000i
50/60/50
110/120/230
Noise Level dB/LpA/LwA/K 4m
(3/4 load)
Only 230V 50Hz with data meter product is GS certificated
.
Inverter Generator Owner's Manual
Troubleshooting
Troubleshooting
Recoil start
Max oil level
Min oil level
GENERATOR WON'T PRODUCE POWER
Safety device (DC protector) to “OFF”…. Press the DC protector
to “ON”.
The AC pilot light Green go off …. Stop the engine, and then restart.
（）
ENGINE CAN'T START
1. Fuel systems
No gasoline in the fire chamber.
No fuel in the fuel tank…add fuel.
Fuel in tank.
Clogged fuel filter …. Clean fuel
filter.
Clogged carburetor…. Clean
carburetor.
2. Engine oil system
Oil level is low…. Add engine oil.
3. Electrical systems
Put the 1 in 3 switch to “CHOKE”
and pull the recoil starter…Poor
spark.
Spark plug dirty with carbon or
wet…. Remove carbon or wipe
spark plug dry.
Faulty ignition system…. Consult
a dealer.franchised
36 37
