GRASS TRIMMER
OPERATOR'S MANUAL
17
NOTE
The spark plug lead and grommet remain in the engine cover.
IMPORTANT
DO NOT use a metal scraper to remove dirt from the cylinder fins.
4. Use the brush to remove dirt from the cylinder fins.
5. Remove grass and leaves from the grid between the recoil starter
and fuel tank.
6. Assemble components in reverse order.
NOTE
When installing the cover, be certain the tabs of the deflector
shield are in the slot of the cover.
EXHAUST SYSTEM
Spark Arrestor Screen
Level 2.
Tools Required: Cross head screwdriver, soft metal brush
Parts Required: Screen, Gasket
WARNING DANGER
During operation the muffler or catalytic muffler and surrounding
cover become hot. Always keep exhaust area clear of flammable
debris during transportation or when storing, otherwise serious
property damage or personal injury may result.
1. Remove engine cover, see "Cooling System Cleaning" pages 17
and 18 for step by step instructions.
2. Remove spark arrestor screen cover (A), gasket (B), and screen (C)
from muffler body.
3. Clean carbon deposits from muffler components.
4. Replace screen if it is cracked, plugged or has holes burned
through.
5. Assemble components in reverse order.
A
B
C

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo GT-200 and is the answer not in the manual?

Echo GT-200 Specifications

General IconGeneral
Engine Displacement21.2 cc
Shaft TypeStraight
Engine Type2-Stroke
Power SourceGasoline
Fuel Tank Capacity11.8 fl oz
Cutting Width16 in
Warranty5 years consumer, 2 years commercial
