Echo POWER PRUNER PPT-265

POWER PRUNER
TM
OPERATOR'S MANUAL
31
SPECIFICATIONS
MODEL ----------------------------------------------------- PPT-265
Length (Standard) ----------------------------------------- 2.72 m (8 ft. 11 in.)
Length (Extended) ----------------------------------------- 3.71 m (12 ft. 2 in.)
Length w/extension ---------------------------------------- 5.23 m (17 ft. 2 in.)
Width -------------------------------------------------------- .25 m (9.8 in.)
Height ------------------------------------------------------- .25 m (9.7 in.)
Weight (dry) ------------------------------------------------ 8.4 kg (18.5 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 34.0 mm (1.34 in.)
Stroke -------------------------------------------------------- 28.0 mm (1.10 in.)
Displacement ----------------------------------------------- 25.4 cc (1.55 cu. in.)
Exhaust System -------------------------------------------- Spark Arrestor Muffler w/catalyst
Carburetor -------------------------------------------------- Zama with Purge
Ignition System -------------------------------------------- CDI (capacitor discharge ignition)
Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ----------------------------------------------- 50 : 1 Power Blend X™ ISO-L-EGD (ISO/CD 13738) and J.A.S.O.
M345- FC/FD, two-stroke, air-cooled engine oil.
Gasoline ----------------------------------------------------- Use 89 Octane unleaded. Do not use fuel containing methyl
alcohol, more than 10% ethyl alcohol or 15% MTBE. Do not use
alternative fuels such as E-20 or E-85.
Oil ------------------------------------------------------------ Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.58 lit. (19.6 US fl. oz.)
Starter System ---------------------------------------------- Automatic Recoil Starter
Clutch ------------------------------------------------------- Centrifugal Type
Sprocket Type ---------------------------------------------- 6 tooth spur, 9.53 mm (3/8 in.) pitch
Power Transmission Shaft Assembly ------------------- Aluminum Extrusion
Gear Case Ratio -------------------------------------------- 1.5:1
Oiling System ----------------------------------------------- Automatic
Saw Chain Oil Capacity ----------------------------------- 225 ml (7.6 oz.)
Handle ------------------------------------------------------- Right hand grip w/throttle trigger and lockout
Shoulder Harness ------------------------------------------ Standard
Idle Speed (RPM) ------------------------------------------ 2,600 - 3,200
Clutch Engagement Speed (RPM) ----------------------- 3,600 - 4,200
Wide Open Throttle Speed (RPM) ----------------------- 9,500 - 11,500
Guide Bar and Saw Chain (91) --------------------------- 305 mm (12 in.); 9.53 mm (3/8 in.) pitch, 0.050 gauge
