18
1. Wipe debris from around oil ll cap.
2. Remove oil ll cap and ll reservoir with a quality, low viscosity
guide bar and saw chain oil.
IMPORTANT
To prevent plastic deterioration, do not use synthetic or silicone
based oil.
adjusTIng auTomaTIC oIler
1. From bottom of gear case, turn adjustment screw (A) clockwise to
decrease oil volume - counter clockwise to increase oil volume.
NOTE
The automatic oiler is preset to deliver a sufcient oil discharge
volume during normal operating conditions. During heavy or dry
cutting conditions, the oil discharge volume may be increased to as-
sure adequate lubrication. If oil is leaking from the bar cover area,
reduce the oil discharge volume. Rell the oil reservoir with each
tank of fuel.
NOTE
Very little visible oil on the saw chain will provide sufcient lubri-
cation.
lubrICaTIng The guIde bar and saw ChaIn
Automatic Oiling System
A
