28
lubrICaTIon
Flexible Drive Shaft
Level 1.
Parts required: POWER BLENDX
TM
14 oz. or Lithium Based
Grease.
1. Loosen clamping screws (A) on driveshaft coupling.
2. Remove handle and exible drive shaft.
3. Remove exible drive shaft (B).
4. Wipe ex shaft clean and apply a thin coating of grease.
5. Slide ex shaft into handle. Leave 2 - 3 inches of ex shaft ex-
posed. DO NOT get dirt on ex shaft.
6. Align exible drive shaft with drive shaft socket, and slide together
until handle is fully seated into drive shaft coupling.
7. Tighten clamping screws (A).
A
B
B
