SPECIFICATIONS PPT-2620
50 X7507820600
© 2/2017 ECHO Inc.
SPECIFICATIONS
Model PPT-2620 PPT-2620H
Length (standard) 2,716 mm (107 in.)
Length (Extended) 3,704 mm (146 in)
Width 273 mm (11 in.)
Height 260 mm (10 in.)
Weight (dry) 7.9 kg (17.4 lb.) 7.7 kg (17 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 34 mm (1.34 in.)
Stroke 28 mm (1.1 in.)
Displacement 25.4 cc (1.55 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w /purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK CMR 7H (Gap 0.65 mm [0.026 in.])
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
or ECHO Red Armor
®
ISO-L-EGD
(ISO/CD 13738) and J.A.S.O. M345- FD
, two-stroke, air-
cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl
alcohol, more than 10% ethyl alcohol or 15% MTBE. Do not
use alternative fuels such as E15 or E85.
Oil
Power Blend X
TM
or ECHO Red Armor
®
Premium Universal
2-Stroke Oil
Fuel Tank Capacity 0.53 L (17.9 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft Aluminum Extrusion
Sprocket Type 6 tooth spur, 9.53 mm (3/8 inch) pitch
Gear Case Ratio 1.5 : 1
Oiling System Automatic
Chain Oil Capacity .2 L (6.76 oz.)
Handles Right hand grip w/throttle trigger and throttle trigger lockout
Shoulder Harness Standard
Idle Speed 3,100
