Maintenance

Cleaning and

Lubricating the Bolt

This procedure can be performed with the Eclipse Ego

gassed up as well as de-gassed.

Raise the bolt pin and remove the bolt and bolt pin from

the Eclipse Ego marker body.

Using a dry Q-tip remove any paint or grease

from the surface of the bolt and seals on the bolt

(See Figure 6.70)

Lubricate the two bolt seals and replace the bolt, locking

the bolt pin into the designated slot in the rammer.

FIGURE 6.70

Note: We recommend the use of light paintgun

oil throughout the Eclipse Ego.
