Eclipse TRILOGY T500 Series - Specification Details; Analog Inputs and Wire Size; Standards and Certifications

16
Eclipse T500 Actuator, V1, Instruction Manual 902, 12/7/2009
Analog Inputs Wire Size
Cross-sectional area of the power supply lines
Standards and Certificates
Conformity of EEC directives:
Electomagnetic compatibility EMC
(immunity) 2004/108/EC
Low voltage directive 2006/95/RC
Parameter Description
Linearity <5%
Control Range 0 to 90°
Voltage Range DC 2 (0) to 10 V
Voltage Input Impedance tkȍ
Current Range DC 4 (0) to 20 mA
Current Input Impedance dkȍ
Potentiometer Range 0 to 135 ȍ, ± 5%
Parameter Description
Line Voltage Terminals Class 1
Min. AWG 18
Suited for 105°C
Max. 2.5mm
2
or AWG 12
Analog Input Terminals Class 2
Min. AWG 22
Suited for 105°C
Max. 1mm
2
or AWG 12
