Eclipse TRILOGY T500 Series User Manual

17
Eclipse T500 Actuator, V1, Instruction Manual 902, 12/7/2009
Dimensions
Figure 4.1.
Slot for woodruff key
3 x 3.7 DIN6888
Connecting cover Europe
Connecting cover US
26.5
93.5
76
50
173.9 (Europe) or 174.7 (US)
122
33
25
Square
20
10.6
O14
9.5 h11
149
15
6
6
2.5 + 0.1
3 N9
#8 - 32
0.6" deep
Round
(Standard)
8
3.7
9.66
10
3
0.39
(10)
0.12
(3)
0.44
(11.2)
6
15
Woodruff Key
