Eclipse TRILOGY T500 Series User Manual

11
Eclipse T500 Actuator, V1, Instruction Manual 902, 12/7/2009
Connection Terminals
Figure 3.8. Connection Terminals (3-Position & 2-Position Step)
3-Position Step
Basic version with
2 end switches and
4 auxiliary switches
X2X1 12 3
V
IV
III
5
M
II
I
VI
23456
1
4 3 1 2
high RED I
low/off BLUE II
ign ORANGE III
aux YELLOW IV
aux BLACK V
aux GREEN VI
Drive High
Neutral
Drive Lo
w/off
Drive to IGN*
IGN Feedb
ack
Low Feedb
ack
High Feedb
ack
Aux
Aux
Aux
* Only when driving from high position
ign - ignition
Connection X2
1 Aux V COM
2 Aux V N.O.
3 High feedback
4 Low feedback
5 Ign feedback
Connector X3
1 Aux VI N.O.
2 Aux VI N.C.
3 Aux VI COM
Connector X1
1 Drive to ign
2 Aux IV N.O.
3 Aux IV COM
4 Neutral
5 Drive low/off
6 Drive high
Ground (Protective Earth)
2-Position Step
Basic version with
2 end switches,
3 auxiliary switches and
one relay
X2X1 12 3
IV
III
5 4 3 1 2
M
II
I
VI
23 4 5 16
a1
K-A
high RED I
low/off BLUE II
ign ORANGE III
aux YELLOW IV
aux GREEN VI
Drive High
Neutral
Drive Lo
w/off
Drive to IGN*
IGN Feedb
ack
Low Feedb
ack
High Feedb
ack
Enable
Drive Open
Aux
Aux
