Eclipse TRILOGY T500 Series - Product Specifications; Operating and Mechanical Specifications; Environmental and Material Specifications

Eclipse T500 Actuator, V1, Instruction Manual 902, 12/7/2009
15
1
At 60 Hz frequency, running times and torques are about 17% less.
Parameter Description
Operating Voltage AC 120 V -15% / +10%
AC 230 V -15% / +10%
Operating Frequency 50 to 60 Hz ±6%
Power Consumption 10 VA
Duty Cycle, ED 100%
Operating Angle Adjustable between 0 and maximum 90° (scale range)
Mounting Position Multi-position
Degree of Protection IP66 / NEMA 4
Cable Entry 2 x M16 without thread or 2 x 1/2" NPT thread
Direction of Rotation Facing the shaft end:
clockwise or counterclockwise, dependent on model
Torque 10 Nm, depending on the type
1
(Holding torque is 5 Nm)
Running Time, 90° stroke 30 seconds depending on the type
1
Drive Motor Synchronous motor, stall protected
Gear Train Maintenance free gears and bearings
End and Auxiliary Switches Type To DIN 41636
Switching Voltage AC 24 to 250 V
Switching Capacity 1A, 250 VAC
7A, 250 VAC Peak load < 0.5 seconds
Number of End Switches 2
Number of Auxiliary Switches Maximum of 4
Drive Shaft Factory supplied, not replaceable
Operating Temperature -20 to +60 °C (0 to 140 °F)
Storage Temperature -40 to +70 °C (-40 to 158 °F)
Humidity <95% RH noncondensing
Weight Approximately 2 kg
Materials of Construction Housing Die Cast Aluminum
Cover Impact-proof and heat resistant plastic
Specifications
4
