1) Turn off the air conditioner and the
power breaker.
2）Remove the screws of the big handle
and then remove the big handle
(2 screws) (see E30_1).
3) Remove the screws of the top cover
and then remove the top cover (4
screws). Two of the screws is located
underneath the big handle (see
E30_2).
4) Remove the screws of water collecting
cover and then remove the water
collecting cover (2 screw) (see E30_3).
To Next Page
