130/157
SDi Decades Extreme Service Manual www.ecoer.com
May. 2023Manufacturer reserves the right to change specifications or designs without notice.
1) Remove 2 screws of the upper cover
Plate assembly and then remove the it.
(see AHU_1)
2) Remove 2 screws and unplug the plugs.
(see AHU_2)
3) Pull out the electric control box
subassembly.(see AHU_2)
Note: This section is for reference only. Actual unit appearance may vary.
9. Indoor Unit Disassembly-Air Handle
9.1 Electrical Parts (Antistatic gloves must be worn.)
To Next Page
