36/157
SDi Decades Extreme Service Manual www.ecoer.com
May. 2023Manufacturer reserves the right to change specifications or designs without notice.
L N
1
2
3
MC MC
4
5
6
Install the indoor unit Install the outdoor unit Install the drainpipe
Connect the wires Connect the refrigerant pipes
Evacuate the refrigeration system
7
Perform a test run
Indoor Unit
Indoor Unit
5. Installation
5.1 Installation Overview
