Ecoer EAHAEC-36 - 5.4 Outdoor Unit Installation; 5.4.1 Service space for outdoor unit; 5.4.2 Bolt pitch

46/157
SDi Decades Extreme Service Manual www.ecoer.com
May. 2023Manufacturer reserves the right to change specifications or designs without notice.
Auxiliary Heater Electrical Data
Heater part
No.
Heater
kW
Internal
Circuit
Protection
CIRCUIT 1
CIRCUIT 2
CIRCUIT 3
Heater
Amps
MCA (1)
MOCP (2)
Heater
Amps
MCA (1)
MOCP
(2)
Heater
Amps
MCA (1)
MOCP
(2)
EAH-
08B(UL)
8
Ckt Bkr
28.8/32.0
37.0/42.0
40.0/45.0
/
/
/
/
/
/
EAH-
10B(UL)
10
Ckt Bkr
36.0/40.0
46.0/53.0
50.0/60.0
/
/
/
/
/
/
EAH-
15B(UL)
15
Ckt Bkr
18.0/20.0
23.0/27.0
25.0/30.0
36.0/40.0
46.0/53.0
50.0/60.0
/
/
/
EAH-
20B(UL)
20
Ckt Bkr
36.0/40.0
46.0/53.0
50.0/60.0
36.0/40.0
46.0/53.0
50.0/60.0
/
/
/
5.4.1 Service space for outdoor unit
Panel Plate
Unit
D
A
B
C
E30
mm
415
634
404
457
inch
16.34
24.96
15.9
17.99
5.4 Outdoor Unit Installation
5.4.2 Bolt pitch
